X-ray Machine RMI 400

Delivers superior bone and contaminant detection. It is designed to NAMI standards, specifically for the meat, poultry and seafood industries where daily sanitation and hygiene requirements are stringent.

Eagle's X-ray System RMI 400
Eagle's X-ray System RMI 400
Eagle's X-ray System RMI 400
Eagle's X-ray System RMI 400
Eagle's X-ray System RMI 400
Eagle's X-ray System RMI 400
Eagle's X-ray System RMI 400
Eagle's X-ray System RMI 400

All the Power of X-ray Analysis

The RMI 400 is hygienically constructed to sanitary design and overcomes the material handling challenges of inspecting raw or unpackaged poultry, seafood and other meats. The machine incorporates an innovative inclined infeed and out-feed conveyor which reduces the number of surfaces product comes into contact with. By eliminating the need for radiation shielding curtains, and with its easy-to-remove belt, sanitation time is reduced for faster and more efficient washdown‒keeping production lines running longer for optimum output. And with Eagle’s PXT™ detector technology, it is capable of detecting bone fragments down to 1 mm in poultry.

Processors can benefit from:

  • Unparalleled detection
  • Lower false rejects
  • Lowest total cost of ownership
  • Easy one-time calibration
All the Power of X-ray Analysis

Machine Specifications

RMI 400

  • Inspection Coverage

    400 mm wide at the belt, 330 mm wide at the top of aperture; 70 mm overall height

  • Inspection Modes

    SimulTask™ 4 PRO standard inspection modes include contaminant, bone, missing item, clip, void, premium, shape/size, position, fill level, count, zonal mass, mass measurement with 2, 3, or 5 zone checkweighing functionality with statistics

  • User Interface & Operating System

    15″ TFT color touch screen; Windows 10 Enterprise LTSB with Eagle SimulTask™ 4 PRO Control & Imaging Software; TeamViewer™ service tool for remote machine diagnostics & product set-up services

  • Conveyor Size

    499 mm (19.6″) wide by 2645 mm (104.1″) Long; Blue homogeneous food-grade urethane non-wicking friction belt compliant for transport of unpackaged foodstuffs

  • Reject Mechanism

    24VDC Signal only, freestanding retracting nose or lift gate reject, custom reject

  • Speed Range

    21 – 61 MPM (70 – 200 FPM), subject to generator & detector used, product type & dimensions

  • X-ray Power

    Single vertical beam; 420W (84kV, 5mA)

  • Detectors Resolution

    0.4 mm, 0.8 mm single energy or PXT™ Performance X-ray Technology

  • Communication

    (2) USB 2.0 ports, (1) Ethernet 10/100/1000 mbps port, (1) RS232 serial port; (1) EtherNet/IP Fieldbus interface port optional

  • IP Rating & Machine Finish

    IP69 Standard; Type 304 Stainless Steel, #4 surface finish less than 32u-inch RA

  • Radiation Safety

    X-ray emissions <1 uS/hr; compliant to 21 CFR 1020.40, 21 CFR 179.21, & EURATOM ER nationalized standards

  • Electrical Safety

    Compliant with CAT-3 (EN954), PLd (EN13849) safety circuits with system visualization

  • Thermal Management

    Water cooled heat exchanger, plant water supply ≥7.6LPM, 13°C to 21°C required; Air conditioner optional

  • Operating Range

    0°C to 40°C (32°F to 104°F) 25% to 90% relative humidity non-condensing

  • Power Requirements

    230 VAC, +/-10%, Single Phase, 50/60 Hz, 16 Amp Fused

  • Options & Accessories

    Multilane operation, product guides, TraceServer™ data collection software, RECON™ rework station, remote user interface, audible & visual alarms, hazard based risk assessment
